Description
The SHACMANLight truck X9 4×2 light duty dump truck (locally addressed as tipper truck or tipper lorry in African markets) represents a cost effective light engineering transportation solution oriented toward small construction contractors, agricultural cooperatives and municipal sanitation departments. Differentiated from heavy duty mining tippers, this X9 dump truck undertakes short cycle material transport assignments such as gravel, sand, earthwork, construction debris, farm produce and domestic refuse. Its hydraulic rear tipping unloading system enables rapid cargo discharge without extra manual handling labor. Gross vehicle weight reaches 8200 kg; compact overall dimension and small turning radius grant access to narrow construction sites, rural village lanes and municipal renovation zones inaccessible for large size dump vehicles. Power assembly deploys YUCHAI YCY24160 60 160 horsepower diesel engine mated to 6 speed manual gearbox, providing sufficient climbing torque on hilly countryside roads. X9 single row cabin supports optional air conditioning configuration to elevate driver comfort under high temperature outdoor working environments.
As a well established Chinese commercial vehicle enterprise, SHACMAN possesses systematic modification capacity for special purpose vehicles on the X9 light truck base platform. All modified tipper vehicles strictly follow unified factory standard technical specifications, implementing multi stage quality inspection covering chassis incoming check, upper assembly welding quality assessment and complete vehicle commissioning. SHACMAN’s overseas market strategy fully targets practical requirements of developing world clients. Abundant field operation feedback collected from Africa and Southeast Asia construction projects has guided chassis suspension calibration and upper body structural optimization of X9 light tipper series. Global service network and spare parts supply system guarantee local maintainability, which is extremely critical for engineering fleets that pursue minimal equipment downtime.
Configuration sheet
Model:SHACMAN Light truck X9 Dump Truck | |
CHASSIS SPECS | |
Curb weight | 3400 kg |
Total weight | 8200 kg |
Drive style | 4×2 |
Engine: | YUCHAI YCY24160-60 diesel engine,160HP |
Transmission: | 6-speed manual gearbox |
Cabin: | X9 single row cab, A/C optional |
Color: | Blue / White / Yellow |
Wheelbase: | 3300 mm |
Tire: | 8.25R16 radial tyre, 6 pcs |
Front axle: | 3.5T |
Rear axle: | 6.8T |
Capacity of oil tank: | 140L |
Others | Power steering, hydraulic tipping system |
CARRIAGE BODY SPECS | |
Size and Specs: | 3400×2000×800mm tipper box, high strength steel, rear tipping cylinder |
Package | Anti-rust paint, hydraulic cylinder protective wrapping |
Advantages
We have been special truck manufacturer for more than 32 years. We has professional German Kogel technology, combined with Sinotruk, to create first-class special vehicles, provide trucks owners with the best quality, best price, and the most timely after-sale professional services.
Shipping
We usually adopt shipping by bulk cargo, flat rack, and Roro ship. We will arrange the most cost-effective transportation mode according to the quantity of products. All trucks will be polished with wax before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
Delivery time
20-40 working days after payment receipt confirmed (based on actual quantity).
Packing
Standard export packing, orcustomized packing as your request.
Professional goods shipping forwarder.
After-sales Service
1.12months or 100,000km for main parts (engine, axle, body and beam, etc).
2.Technical Support by phone Whatsapp or email around the clock.
3.Lifelong Parts Supports
4.Engineer available service oversea
