Description
FAW Tiger V (commonly known as Huwei) refuse compactor truck is a medium and small-sized sanitation waste collection equipment built on the dedicated Tiger VH light truck chassis. It is specially designed for domestic waste collection in narrow scenarios such as urban back streets, old communities and township towns, serving as a cost-effective solution for refined sanitation operations.
The vehicle is equipped with a proven and reliable diesel powertrain with a solid load-bearing chassis. Its compact and agile body with a small turning radius can easily access narrow sections that traditional large garbage trucks cannot reach, realizing full coverage of waste collection. The upper body is welded from high-strength wear-resistant steel plate and equipped with an electro-hydraulic driven bidirectional compaction mechanism. With a high waste compaction ratio, it greatly increases the single-trip loading capacity, reduces the frequency of round trips to landfills, and significantly cuts operational fuel consumption and labor costs.
The tank adopts a fully sealed structure with a built-in sewage collection chamber, which effectively prevents waste scattering and leachate dripping during transportation and avoids secondary pollution. The operation process can be completed with one button through the electric control system in the cab, which is simple and efficient, and greatly reduces the work intensity of sanitation workers. With highly universal spare parts and convenient, economical maintenance, it can be adapted to various feeding devices such as hanging buckets and shovels to meet waste collection demands in different scenarios.
Configuration sheet
| Model: CA1041P40K50L1BE6A84 | |
| CHASSIS SPECS | |
| Curb weight | 3900kgs |
| Total weight | 4495kgs |
| Drive style | 4×2 |
| Engine: | Quanchai Q23-95E60, 70kW (95PS), 2300ml displacement, diesel fuel, Euro 6 emission |
| Transmission: | Matched manual gearbox |
| Cabin: | 2-seater single-row cab |
| Color: | Multiple options available |
| Wheelbase: | 2800 mm |
| Tire: | 6.50R16 / 195/70R15, 6 units |
| Front axle: | 2060kg axle load, 1520mm wheel track |
| Rear axle: | 2435kg axle load, 1475mm wheel track |
| Capacity of oil tank: | Standard fuel tank |
| Others | Max speed 95km/h; approach angle 15°/18°, departure angle 15°/15°; front overhang 1155mm, rear overhang 1760mm/1820mm |
| CARRIAGE BODY SPECS | |
| Size and Specs: | Overall dimension 5775/5995 × 1900/2050 × 2230/2330 mm; fully sealed refuse compartment with slide-scraper compaction mechanism, push shovel, loading device, electro-hydraulic control system; built-in sewage collection tank to avoid secondary pollution during transportation |
| Package | Wax |
Advantages
We have been special truck manufacturer for more than 32 years. We has professional German Kogel technology, combined with Shacman, to create first-class special vehicles, provide trucks owners with the best quality, best price, and the most timely after-sale professional services.
Shipping
We usually adopt shipping by bulk cargo, flat rack, and Roro ship. We will arrange the most cost-effective transportation mode according to the quantity of products. All trucks will be polished with wax before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
Delivery time
20-40 working days after payment receipt confirmed (based on actual quantity).
Packing
Standard export packing, orcustomized packing as your request.
Professional goods shipping forwarder.
After-sales Service
1.12months or 100,000km for main parts (engine, axle, body and beam, etc).
2.Technical Support by phone Whatsapp or email around the clock.
3.Lifelong Parts Supports
4.Engineer available service oversea.
