Description
Whether it’s fuel supply for mining sites, remote construction projects, or bulk delivery of diesel and gasoline, the SHACMAN F3000 fuel tanker can handle the task perfectly.
Equipped with a reliable Weichai engine, the vehicle delivers stable and sufficient power. It performs well under heavy-load conditions and adapts to long-distance travel as well as various rough and complicated road conditions.
The tank volume has a wide selection range, with a minimum of 3000 liters and a maximum optional capacity of 40000L. Multiple drive options are available for the chassis, including 4×2, 6×4 and 8×4 to meet different transportation volume requirements. The whole vehicle is fitted with a full set of safety protection components such as explosion-proof emergency shut-off valves and static grounding devices to fully control risks during fuel transportation. The spacious and comfortable cab helps reduce driver fatigue during long working hours.
The vehicle comes with a professional oil loading and unloading system, which enables fast filling and discharging of oil products and greatly improves transfer efficiency.
Multiple anti-surge baffles are installed inside the tank to reduce the impact of fuel during driving and enhance vehicle stability. Choose the SHACMAN F3000 fuel tanker. It is your trustworthy partner for bulk fuel transportation!
Configuration sheet
| Model: SX5255GYYDN434 | |
| CHASSIS SPECS | |
| Curb weight | 13000 kgs |
| Total weight | 25000 kgs |
| Drive style | 6×4 |
| Engine: | WP10.300E22, 300HP, Euro II emission |
| Transmission: | RTD-11509C with QH50 flange power take-off |
| Cabin: | Mid-long flat roof cabin, 4-point hydraulic suspension |
| Color: | White |
| Wheelbase: | 4375+1400 mm |
| Tire: | 12.00R20 |
| Front axle: | HD 7.5T |
| Rear axle: | 13T HD double-stage reduction, gear ratio 5.262 |
| Capacity of oil tank: | 300L aluminum alloy fuel tank |
| Others | Standard air filter, standard steering wheel, rear-mounted exhaust pipe with spark arrestor |
| CARRIAGE BODY SPECS | |
| Size and Specs: | Tank volume 20000L; tank shell thickness: 5mm; head thickness: 5mm; baffle thickness:3mm |
| Package | Wax |
Advantages
We have been special truck manufacturer for more than 32 years. We has professional German Kogel technology, combined with Shacman, to create first-class special vehicles, provide trucks owners with the best quality, best price, and the most timely after-sale professional services.
Shipping
We usually adopt shipping by bulk cargo, flat rack, and Roro ship. We will arrange the most cost-effective transportation mode according to the quantity of products. All trucks will be polished with wax before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
Delivery time
20-40 working days after payment receipt confirmed (based on actual quantity).
Packing
Standard export packing, orcustomized packing as your request.
Professional goods shipping forwarder.
After-sales Service
1.12months or 100,000km for main parts (engine, axle, body and beam, etc).
2.Technical Support by phone Whatsapp or email around the clock.
3.Lifelong Parts Supports
4.Engineer available service oversea.
